Number of Cavity :- 4 Cavity (Upto 1 Ltr.) & (2 Cavity 2 Ltr.)
.png)
Bottle Output :- 5400 - 6000 BPH (90-100 8PM)
Container Volume :- 200 ML to 1 Ltr. & 2 Ltr. (Option)
Max Bottle Diameter & Bottle Hight :- 85 mm & 280 mm (350 mm)
.png)
Max. Preform Neck Diameter & Preform Height :- 25-30 mm & 145 mm
Total Power Connected Load (1 LTR) :- 38 Kw
.png)
Actual Power Consumption (1 LTR) :- 19 Kw
.png)
Voltage Stabilizer Requirement :- 60 KVA( 415V 3Φ , 50Hz)
Low Pressure Compressor Requirement :- Not Required
High Pressure Compressor Requirement :- 155-165 CFM @ 28-30 BAR
.png)
Water Chiller Requirement(100 LPM@3BAR) :- 5 TR (8-10° c)
Number of Cavity :- 4 Cavity (Upto 1 Ltr.) & (2 Cavity 2 Ltr.)
Bottle Output :- 7200 BPH (120 BPM)
Container Volume :- 200 ML to 1 Ltr. & 2 Ltr. (Option)
Max Bottle Diameter & Bottle Hight :- 85 mm & 280 mm (350 mm)
Max. Preform Neck Diameter & Preform Height :- 25-30 mm & 145 mm
Total Power Connected Load (1 LTR) :- 49 Kw
Actual Power Consumption (1 LTR) :- 29 Kw
Voltage Stabilizer Requirement :- 75 KVA( 415V 3Φ , 50Hz)
Low Pressure Compressor Requirement :- Not Required
High Pressure Compressor Requirement :- 200 CFM @ 28-30 BAR
Water Chiller Requirement(100 LPM@3BAR) :- 7.5 TR (8-10° c)
200 ML
500 ML
1 Ltr.
1.5 Ltr.
2 Ltr.
